HY-4015 -- 3000W fiber laser cutting machine

Serial Number

Component Name

Brand

Model

Quantity

Origin

1

fiber laser generator

Chuangxin

3000W

1

Shenzhen

`2

optical fiber cutting head

Potts/Jiaqiang

110

1

Shanghai

3

Optical Lenses

Ophir

F1

1 set

Israel

4

numerical control system

Berchu 2000E

2000E

1 set

Shanghai

5

automatic oil filling

1 set

Domestic

6

Servo motor driver

Fuji

Sleeve

Japan

7

Reducer

new treasure

V

3 sets

Japan

8

gear rack

YYC Rack

M2-6 grinding

3 sets

Taiwan

A9

Linear guide

upper silver

HGH

3 sets

Taiwan

10

Low-voltage electrical apparatus

Schneider/
Delixi

A9

1 set

France

11

water-cooled machine

Hanli/Huaku

3000W

1

China Sea

12

Proportional valve

SMC

1 set

Main technical indexes of HY-4015-3000W fiber laser cutting machine

Serial Number

Performance index parameters

Remarks

1

Processing width (length * width)

1500mmX4000mm

2

X-axis travel

1500mm

3

Y-axis travel

3000mm

4

Z-axis travel

100mm

5

X/Y axis positioning accuracy

±0.04mm/m

6

X/Y axis repeat positioning accuracy

±0.03mm

7

X/Y axis backlash

0.015mm

8

Acceleration

0.8G

9

X/Y axis composite speed

50m/min

10

Machine weight

2000KG

11

Maximum load of workbench

1000KG

12

The whole machine covers an area

3000mm*5000mm*1630

13

Protection grade of total power supply

IP54

14

Cold moving mode

Water cooling
